Yazan Steel, located in Amman, Jordan, is a reliable manufacturer and supplier of specialized steel products designed for both pressure and thermal applications. They provide IS 2002 Grade 1, Grade 2, and Grade 3 Boiler Sheets and Plates, all crafted in line with the Indian Standard IS 2002 for boiler and pressure vessel use. These grades are celebrated for their dependable strength, consistent quality, and outstanding performance even at high temperatures. Yazan Steel is committed to rigorous quality control, precise dimensions, and adherence to standards, ensuring they meet the needs of the power, refinery, and process industries.
The IS 2002 boiler grades are made from carbon steel with a carefully controlled chemical composition, which includes carbon, manganese, silicon, sulfur, and phosphorus within defined limits. Grade 1 is characterized by lower strength but higher ductility, while Grades 2 and 3 offer progressively greater tensile and yield strength. These sheets and plates are known for their good elongation, excellent weldability, and resistance to thermal stress, making them well-suited for the pressure and temperature fluctuations typical in boiler service.
| Width | 1000mm-4500mm |
|---|---|
| Thickness | 5mm-150mm |
| Length | 3000mm-18000mm |
| Impact tested | -52° C |
| Material | Pressure Vessel Steel / Boiler Quality |
| Process of Manufacturing | Hot-Rolled (HR) |
| Grade | C | Si | P | S |
| IS 2002 Gr 1 | 0.18 | 0.10 – 0.35 max | 0.40 max | 0.040 max |
| IS 2002 Gr 2 | 0.20 | 0.10 – 0.35 max | 0.50 max | 0.050 max |
| IS 2002 Gr 3 | 0.22 | 0.10 – 0.35 max | 0.50 max | 0.050 max |
| A517 / SA517 Grade B | Tensile Strength (MPa) | Yield Strength (Min MPa) | Elongation min (%) |
| IS 2002 Gr 1 | 37 – 45 | 55 | 26-30% |
| IS 2002 Gr 2 | 42 – 50 | 50 | 25-29 % |
| IS 2002 Gr 3 | 52 – 62 | 50 | 20-24 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Yazan Steel is one of the most prominent manufacturers and suppliers of superior quality IS 2002 Gr1/Gr2/Gr3 Boiler Sheet and Plate in Amman, Jordan. As experts in steel solutions, we supply a complete spectrum of products like Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our product range comprises Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Known for our reliable delivery and first-rate customer service, we are committed to supplying high-quality steel materials that guarantee durability and excellent performance in numerous industrial applications.
IS 2002 boiler sheets and plates find extensive use in the fabrication of boilers, pressure vessels, and heat-retaining equipment. Common applications include steam boilers, drums, headers, heat exchangers, and industrial furnaces. They are also utilized in refineries, petrochemical plants, power generation facilities, and process industries that manage pressurized fluids and gases. Thanks to their ability to endure high temperatures and internal pressure, these grades are the go-to choice for critical thermal and pressure applications that demand safety, durability, and a long service life.
Yazan Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Amman, Jordan.
