Located in the industrial heart of Amman, Jordan, Yazan Steel stands as a dedicated manufacturer and supplier of specialized steel solutions. We take pride in producing HIC Resistant Steel Sheet and Plate, a critical material engineered for some of the world’s most demanding environments. Our commitment is to provide local and regional industries with robust, high-integrity products that ensure longevity and safety, supporting vital infrastructure and energy projects with unwavering quality and reliability directly from our facilities.
The strength of this steel lies in its specialized composition, which is carefully controlled to include low levels of sulfur and phosphorus. This precise chemistry is key to its remarkable ability to resist the damaging effects of hydrogen, preventing the internal cracking that can compromise ordinary steel. As a result, these plates offer exceptional mechanical properties, including high tensile strength and excellent toughness, ensuring they maintain their integrity even under intense pressure and in corrosive service conditions.
| Material | ASTM A516 |
| Grade | SA516 Gr 65, SA516 Gr 70 ,SA516 Gr 60 , Gr 60N |
| Size |
|
| Manufacturing Process | Â Hot-Rolled |
| Impact tested | -52° C |
Technical requirements | high strength and high toughness requirements, Detection, Z15 – Z35 thickness direction performance requirements, etc |
| Condition of Supply | Heat Treatment Simulated Post-Weld , Furnace Normalizing, As Rolled, Normalized Rolling, Vacuum Degassing or as per need |
| Base Plate | hot dipped zinc coated and  A-Z coated steel sheet, Cold rolled steel sheet |
Â
| C | ≤0.2 |
| Mn | 0.85–1.20 |
| Cu | ≤0.2 |
| Cev | ≤0.41 |
| S | ≤0.001 |
| Si | 0.15–0.40 |
| P | ≤0.010 |
| Mo | ≤0.1 |
| Ni | ≤0.4 |
| Cr | ≤0.3 |
| ASTM/ASME | DIN | European Norm | British Standard |
| A/SA516 – Grade 60 | DIN 17155 HII | EN10028 P265GH | BS1501-161-430A |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Grade | Plates Thickness |
|---|---|
| A516 60 | ≤12.5mm |
| A516 60 | ≥100 and ≤200mm |
| A516 60 | ≥12.5 mm and ≤50mm |
| A516 60 | >200mm |
| A516 65 Dicrest only | ≥100 mm and ≤200mm |
| A516 60 | ≥50 mm and ≤100mm |
| A516 65 Dicrest only | ≤12.5mm |
| A516 65 Dicrest only | ≥12.5 mm and ≤50mm |
| A516 65 Dicrest only | ≥50 mm and ≤100 mm |
| A516 70 | >200 mm |
| A516 65 Dicrest only | >200mm |
| A516 70 | ≥100 mm and ≤200mm |
| A516 70 | ≤12.5mm |
| A516 70 | ≥50 mm and ≤100mm |
| A516 70 | ≥12.5 mm and ≤50mm |
| Lengths in mm | Plates Thickness in Inches | Widths in mm | Lbs/Sft |
|---|---|---|---|
| 240 | 7/16 Inches | 96 | 17.870 Lbs/Sft |
| 96, 120, 240 | 5/16 Inches | 60 ,48 , 84 , 72 ,96 | 12.760 Lbs/Sft |
| 96, 120, 124,133, 144, 156, 240 | 3/16 Inches | 7.660 Lbs/Sft | |
| 110, 96, 120, 240, 144 | 1/4 Inches | 10.210 Lbs/Sft | |
| 120, 96, 144, 169, 240, 260 | 3/8 Inches | 15.320 Lbs/Sft | |
| 120, 96, 144, 240 | 1/2 Inches | 20.420 Lbs/Sft | |
| 240 | 1 1/8 Inches | 96 | 45.950 Lbs/Sft |
| 96, 240, 120, 480 | 1 Inches | 48, 72, 96 | 40.840 Lbs/Sft |
| 96, 240, 120, 480 | 3/4 Inches | 48 , 72 , 84, 96 | 30.630 Lbs/Sft |
| 240 | 7/8 Inches | 96 | 35.740 Lbs/Sft |
| 240, 120, 480 | 5/8 Inches | 48 , 96 | 25.530 Lbs/Sft |
| 96, 120, 240 | 1 1/4 Inches | 48, 96 | 51.050 Lbs/Sft |
| 120, 240 | 1 1/2 Inches | 96 | 61.260 Lbs/Sft |
| 240 | 1 3/4 Inches | 71.470 Lbs/Sft | |
| 240 | 1 3/8 Inches | 56.160 Lbs/Sft | |
| 120, 240 | 2 Inches | 81.680 Lbs/Sft | |
| 240 | 2 1/2 Inches | 102.100 Lbs/Sft | |
| 1 5/8 Inches | 66.370 Lbs/Sft | ||
| 2 3/4 Inches | 112.310 Lbs/Sft | ||
| 2 1/4 Inches | 91.890 Lbs/Sft | ||
| 3 Inches | 122.520 Lbs/Sft | ||
| 120 | 3 1/2 Inches | 142.940 Lbs/Sft | |
| 120 | 6 Inches | 245.040 Lbs/Sft | |
| 120 | 3 3/4 Inches | 153.150 Lbs/Sft | |
| 144 | 3 1/4 Inches | 132.730 Lbs/Sft | |
| 144, 180 | 4 Inches | 163.360 Lbs/Sft | |
| 120 | 4 1/2 Inches | 183.780 Lbs/Sft | |
| 120 | 4 1/4 Inches | 173.570 Lbs/Sft | |
| 144 | 5 Inches | 204.200 Lbs/Sft | |
| 160 | 7 Inches | 285.880 Lbs/Sft |
This unique resistance makes our HIC plates indispensable in sectors where failure is not an option. They are the material of choice for constructing pressure vessels, critical pipelines, and massive storage tanks within the oil and gas industry, particularly in sour service environments. Furthermore, their reliability is crucial for chemical processing plants and offshore platforms, safeguarding both infrastructure and personnel by preventing catastrophic equipment failures and ensuring long-term operational safety.
