EN 10025-2 S690Q Sheet and Plates are top-notch structural steel products built for situations that demand outstanding load-bearing capabilities and exceptional performance in tough conditions. As a quenched and tempered steel, S690Q boasts a minimum yield strength of 690 MPa, making it perfect for lightweight yet sturdy structural designs. These plates are known for their impressive toughness, weldability, and fatigue resistance, ensuring they perform reliably in environments that face dynamic or heavy stresses. Their remarkable strength-to-weight ratio allows engineers to cut down on structural weight without sacrificing safety or durability, which is why S690Q is a go-to choice for cutting-edge engineering and construction projects.
The chemical makeup of S690Q generally includes carefully controlled amounts of carbon, manganese, chromium, molybdenum, and nickel, all of which boost hardenability, strength, and toughness. Its mechanical properties feature high yield and tensile strength, excellent impact energy absorption even in low temperatures, and consistent dimensional stability. These traits enable the material to withstand extreme loads, harsh weather, and demanding operational environments.
| Item | Quenched And Tempered Structural Steel Plate |
|---|---|
| Material | QUARD, SUMIHARD, BRINAR, DUROSTAT, DILLIDUR, JFE EVERHARD |
| Thickness | 3 – 200mm |
| Width | 500 – 3000mm |
| Length | 1000 – 12000mm |
| Heat Treatment | N, Q+T |
| Surface Paint | EP, PE, HDP, SMP, PVDF |
| C | Si | Мn | P | S | N | B | Сr | Сu | Мо | Nb | Ni | V |
| 0.20 max.(%) | 0.80 max.(%) | 1.70 max.(%) | 0.020-0.025 | 0.010-0.015 | 0.015 max.(%) | 0.005 max.(%) | 1.50 max.(%) | 0.50 max.(%) | 0.70 max.(%) | 0.06 max.(%) | 2.00 max.(%) | 0.12 max.(%) |
| Steel Grade | Thickness, mm | Yield strength, min MPa | Tensile strength, MPa | Elongation, min % |
| S690QL | ≥8 t ≤50 | 690 | 770-940 | 14 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Standard | ASTM | DIN, WNr | JIS | AFNOR | ISO 4952 |
| EN 10025-2:2004 | A709-100 | TStE690V DILLIMAX 690 NAXTRA 70 | JFE HITEN 780LE | E690T E690TFP S690T | E690 |
Yazan Steel is a top manufacturer and supplier of high-quality EN 10025-2 S690Q Sheet and Plates products in Amman, Jordan. Specializing in steel solutions, we provide a wide range of products, including Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel. Our offerings include Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates. Known for our reliable delivery and superior customer service, we are committed to offering top-tier steel materials that ensure durability and performance across a wide range of industrial applications. We strive to meet the highest standards, making us a trusted partner for all your steel needs.
EN 10025-2 S690Q Sheet and Plates find their place in crane booms, bridges, lifting equipment, heavy machinery, truck frames, mining gear, and high-performance structural components. Their blend of strength, toughness, and weldability makes them perfect for applications where safety, reduced weight, and longevity are essential. Engineers and fabricators often choose S690Q for innovative structural designs that require maximum performance with minimal material thickness.
