Yazan Steel stands out as a top-notch manufacturer and supplier located in Amman, Jordan, focusing on high-quality Carbon Steel JIS G3455 Pipes tailored for demanding industrial needs. Known for its reliability and precision engineering, the company adheres to international standards, providing robust piping solutions that excel in high-pressure environments. By blending cutting-edge production technology with rigorous quality control, Yazan Steel ensures that its pipes offer durability, consistency, and long-lasting performance. The company proudly serves various sectors, including power generation, petrochemicals, and mechanical systems, and is dedicated to delivering exceptional products and outstanding customer support in both local and regional markets.
Carbon Steel JIS G3455 Pipes are made up of a mix of carbon, manganese, silicon, phosphorus, and sulfur, all carefully balanced to achieve optimal strength and toughness. These pipes boast impressive mechanical properties, such as high tensile strength, good yield strength, and reliable elongation, making them ideal for pressure-bearing applications. Their remarkable hardness, impact resistance, and ability to handle high temperatures make them perfect for high-pressure settings. Plus, their weldability and machinability enhance fabrication efficiency, making JIS G3455 pipes a trusted choice for boiler systems, heat exchangers, and general mechanical piping.
| JIS Standard | : | JIS G3455 |
| JIS G3455 Grade | : | STS480, STPG 410, STPG 370 |
| JIS G3455 Wall Thickness | : | 1.0mm – 20 mm THK |
| JIS G3455 Outer Dimensions | : | 6mm – 150mm |
| JIS G3455 | C | Si | Mn | P | S |
|---|---|---|---|---|---|
| STPG 370 | 0.25 max. | 0.10-0.35 | 0.30-1.10 | 0.035 | 0.035 |
| STPG 410 | max 0.30 | 0.10-0.35 | 0.30-1.40 | 0.035 | 0.035 |
| JIS G3455 | Yield Strength | Tensile Strength | Elongation A5 min | |||
| MPa min | ksi min | MPa min | MPa min | ksi min | Percentage | |
| STS 370 | 370 | – | – | 30 | ||
| STS 410 | 410 | – | – | 25 | ||
| STS 480 | 480 | – | – | 25 | ||
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Jaxon Steel is a trusted manufacturer and supplier of high-quality Carbon Steel JIS G3455 Pipe products in Amman, Jordan. Specializing in premium steel materials, we offer a wide range of products, including Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our extensive inventory includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. With a commitment to timely delivery and exceptional customer service, Jaxon Steel ensures the supply of top-grade materials that deliver outstanding performance in demanding industrial applications. Count on Jaxon Steel for all your Carbon Steel JIS G3455 Pipe requirements.
| Permissible Specified Outside Diameter and Specified Wall Thickness | ||
Specified Outside Diameter D mm (in.) | Specified Wall Thickness t mm (in.) | |
| Special Light Sizes a | Regular Sizes | |
| ≥ 10.3 (0.405) to < 13.7 (0.540) | — | ≥ 1.7 (0.068) to ≤ 2.4 (0.094) |
| ≥ 13.7 (0.540) to < 17.1 (0.675) | — | ≥ 2.2 (0.088) to ≤ 3.0 (0.118) |
| ≥ 17.1 (0.675) to < 21.3 (0.840) | — | ≥ 2.3 (0.091) to ≤ 3.2 (0.125) |
| ≥ 21.3 (0.840) to < 26.7 (1.050) | — | ≥ 2.1 (0.083) to ≤ 7.5 (0.294) |
| ≥ 26.7 (1.050) to < 33.4 (1.315) | — | ≥ 2.1 (0.083) to ≤ 7.8 (0.308) |
| ≥ 33.4 (1.315) to < 48.3 (1.900) | — | ≥ 2.1 (0.083) to ≤ 10.0 (0.394) |
| ≥ 48.3 (1.900) to < 60.3 (2.375) | — | ≥ 2.1 (0.083) to ≤ 12.5 (0.492) |
| ≥ 60.3 (2.375) to < 73.0 (2.875) | ≥ 2.1 (0.083) to ≤ 3.6 (0.141) | > 3.6 (0.141) to ≤ 14.2 (0.559) |
| ≥ 73.0 (2.875) to < 88.9 (3.500) | ≥ 2.1 (0.083) to ≤ 3.6 (0.141) | > 3.6 (0.141) to ≤ 20.0 (0.787) |
| ≥ 88.9 (3.500) to < 101.6 (4.000) | ≥ 2.1 (0.083) to ≤ 4.0 (0.156) | > 4.0 (0.156) to ≤ 22.0 (0.866) |
| ≥ 101.6 (4.000) to < 168.3 (6.625) | ≥ 2.1 (0.083) to ≤ 4.0 (0.156) | > 4.0 (0.156) to ≤ 25.0 (0.984) |
| ≥ 168.3 (6.625) to < 219.1 (8.625) | ≥ 2.1 (0.083) to ≤ 4.0 (0.156) | > 4.0 (0.156) to ≤ 40.0 (1.575) |
| ≥ 219.1 (8.625) to < 273.1 (10.750) | ≥ 3.2 (0.125) to ≤ 4.0 (0.156) | > 4.0 (0.156) to ≤ 40.0 (1.575) |
| ≥ 273.1 (10.750) to < 323.9 (12.750) | ≥ 3.6 (0.141) to ≤ 5.2 (0.203) | > 5.2 (0.203) to ≤ 45.0 (1.771) |
| ≥ 323.9 (12.750) to < 355.6 (14.000) | ≥ 4.0 (0.156) to ≤ 5.6 (0.219) | > 5.6 (0.219) to ≤ 45.0 (1.771) |
| ≥ 355.6 (14.000) to < 457 (18.000) | ≥ 4.5 (0.177) to ≤ 7.1 (0.281) | > 7.1 (0.281) to ≤ 45.0 (1.771) |
| ≥ 457 (18.000) to < 559 (22.000) | ≥ 4.8 (0.188) to ≤ 7.1 (0.281) | > 7.1 (0.281) to ≤ 45.0 (1.771) |
| ≥ 559 (22.000) to < 711 (28.000) | ≥ 5.6 (0.219) to ≤ 7.1 (0.281) | > 7.1 (0.281) to ≤ 45.0 (1.771) |
| ≥ 711 (28.000) to < 864 (34.000) | ≥ 5.6 (0.219) to ≤ 7.1 (0.281) | > 7.1 (0.281) to ≤ 52.0 (2.050) |
| ≥ 864 (34.000) to < 965 (38.000) | — | ≥ 5.6 (0.219) to ≤ 52.0 (2.050) |
| ≥ 965 (38.000) to < 1422 (56.000) | — | ≥ 6.4 (0.250) to ≤ 52.0 (2.050) |
| ≥ 1422 (56.000) to < 1829 (72.000) | — | ≥ 9.5 (0.375) to ≤ 52.0 (2.050) |
| ≥ 1829 (72.000) to < 2134 (84.000) | — | ≥ 10.3 (0.406) to ≤ 52.0 (2.050) |
In industries where transporting high-pressure fluids is crucial, Carbon Steel JIS G3455 Pipes are a go-to solution. They’re frequently used in boilers, heat exchangers, and steam piping systems thanks to their outstanding strength and thermal resistance. Power plants, petrochemical facilities, and oil and gas refineries depend on these pipes to safely and efficiently convey steam, gas, and high-temperature fluids. Additionally, they find applications in mechanical structures, hydraulic lines, and industrial processing equipment. Their durability and corrosion resistance make them a reliable choice for a wide range of uses.
Yazan Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Amman, Jordan.
