Yazan Steel, based in Amman, Jordan, stands out as a trusted manufacturer and supplier of Carbon Steel A106 Grade C Pipes, providing top-notch piping solutions for demanding industries. These pipes are crafted to meet ASTM A106 standards and are designed specifically for high-temperature and high-pressure applications. With state-of-the-art manufacturing facilities and rigorous quality control measures, Yazan Steel guarantees consistent chemical composition, precise dimensions, and outstanding surface quality. The Carbon Steel A106 Gr C Pipes from Yazan Steel are recognized for their exceptional strength, durability, and reliable performance in critical operating conditions.
The composition of Carbon Steel A106 Gr C Pipe includes iron with a carbon content of up to 0.35%, manganese up to 1.20%, and limits on phosphorus and sulfur at 0.035% each, along with a minimum silicon content of 0.10%. This blend boosts strength and toughness while ensuring good weldability. In terms of mechanical properties, the pipe boasts a minimum tensile strength of about 485 MPa and a minimum yield strength of around 275 MPa, making it the strongest option among ASTM A106 pipes for pressure service.
| Standard Specification | ASTM A 106, ASME SA 106 (Grade C) |
| Codes and Standards | ANSI, ASME, ASTM, API, SAE, BS, AGA, AWWA, ISO, DIN |
| Dimensions | ASME/ ANSI B36.10 / 19 |
| Standard Size | 1/2” NB to 36” NB (LSAW, SSAW, HSAW) |
| Wall Thickness | 3-12mm |
| Pipes schedules | SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS |
| Producing techniques | Seamless / ERW / Welded / Fabricated / CDW / EFW |
| Types | Round, Half Round, Square, Rectangular or Custom shape |
| Length | 3 to Max18 Meters or custom |
| End | Beveled End, Plain End, Treaded |
| Test Certificate | EN 10204 3.1 B |
| Grade | MFG. | C max | Mn* | P max | S max | Si min | Cr˟ max | Cu˟ max | Ni˟ max | Mo˟ max | V˟ max |
|---|---|---|---|---|---|---|---|---|---|---|---|
| C | SMLS | 0.35* | 0.29-1.06 | 0.035 | 0.035 | 0.10 | 0.40 | 0.40 | 0.40 | 0.15 | 0.08 |
| Grade | Process | Tensile Strength (MPa) Min | Yield Strength (MPa) Min | Elongation in 2” (%) MinimumLong. Strip Test | Elongation in 2” (%) MinimumTrans. Strip Test |
|---|---|---|---|---|---|
| C | SMLS | 70,000 [485] | 40,000 [275] | 30 | 16.5 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Minimal Pipes Size [DN Designator] | Under | Over | ||
| mm | in. | mm | in. | |
| 1/8 to 1-1/2 [6 to 40], incl | 0.4 | 1/64 (0.015) | 0.4 | 1/64 (0.015) |
| Over 1-1/2 to 4 [40 to 100], incl | 0.8 | 1/32 (0.031) | 0.8 | 1/32 (0.031) |
| Over 4 to 8 [100 to 200], incl | 0.8 | 1/32 (0.031) | 1.6 | 1/16 (0.062) |
| Over 8 to 18 [200 to 450], incl | 0.8 | 1/32 (0.031) | 2.4 | 3/32 (0.093) |
| Over 18 to 26 [450 to 650], incl | 0.8 | 1/32 (0.031) | 3.2 | 1/8 (0.125) |
| Over 26 to 34 [650 to 859], incl | 0.8 | 1/32 (0.031) | 4.0 | 5/32 (0.156) |
| Over 34 to 48 [850 to 1200], incl | 0.8 | 1/32 (0.031) | 4.8 | 3/16 (0.187) |
Yazan Steel is a top manufacturer and supplier of high-quality Carbon Steel A106 Gr C Pipe products in Amman, Jordan. Specializing in steel solutions, we provide a wide range of products, including Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel. Our offerings include Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates. Known for our reliable delivery and superior customer service, we are committed to offering top-tier steel materials that ensure durability and performance across a wide range of industrial applications. We strive to meet the highest standards, making us a trusted partner for all your steel needs.
Carbon Steel A106 Gr C Pipes are extensively utilized in harsh service conditions that involve high pressure and elevated temperatures. They’re commonly found in oil and gas processing facilities, petrochemical plants, thermal and nuclear power stations, and refinery piping systems. These pipes are also well-suited for steam lines, high-pressure boilers, heat exchangers, and critical process piping. Their enhanced mechanical strength and resistance to thermal stress make them perfect for applications that demand long-term reliability and safety.
